|AHM1 (2016)||AHM2 (2021)|
This is the permanent book web site of the Applied hierarchical modeling (AHM) project. AHM primarily comprises two volumes of a book with the same main title (but different subtitles) and the R package AHMbook, which can be downloaded from CRAN.
On this website you find a short introduction to hierarchical modeling, especially to what we call explicit hierarchical models, on the philosophy of applied statistical modeling espoused in the AHM project, and then a brief overview of the contents of the two books. We also give pointers to important associated resources, including websites, software, and other stuff.... If you're in a hurry please just scroll down.
For a more dynamical (i.e., more frequently updated) AHM page, see our Google page here [https://sites.google.com/site/appliedhierarchicalmodeling/home] (although RIGHT now it is blocked due to some automatic migration process).
HMs have many advantages. A major benefit is simply that a hierarchical representation of a statistical model often makes model fitting much easier in practice and sometimes only doable in the first place. Even more importantly perhaps, the way in which a complex joint probability is factorized into conditional probability expressions is typically guided by our understanding of the processes that underlie a particular data set. The act of hierarchical modeling thus naturally enforces a focus on processes. As a result, we (and others, too) like to claim that hierarchical modeling leads to more scientific statistical models, or at least to scientifically more interesting and relevant models that naturally represent the hypothesized mechanisms in our science or management problem. A hallmark of HMs is a rich latent structure, i.e., hidden or partially hidden stochastic processes that produce latent variables, or random effects.
HMs have a fairly long history in statistics going back at least to the 1970s. They gained a lot of traction in the 1990s, catalyzed by the computational revolution that led to widespread adoption of MCMC methods and to the great revival of Bayesian methods in statistics.
In ecology and the environmental sciences, this was evidenced by a short, but highly influential, paper by Mark Berliner in 1996, who was a mentor to Andy Royle and Chris Wikle. However, there is a vast variety of HMs and the mere term, hierarchical model, really conveys hardly any information about the actual type of model being fitted. 'HM' says more about how a statistical model is constructed, rather than about the particular model itself.
Very commonly, HMs are used to accommodate unexplained dependencies in the data in space or in time, which can be accommodated conveniently by correlated latent variables. The random effects in this sort of HMs are usually completely hypothetical constructs that have no real-world meaning whatsoever. Andy Royle and Bob Dorazio call such HMs 'implicit HMs.'
Such implicit hierarchical models can be very useful on many occasions, and they have been particularly influential in spatio-temporal modeling. We also use them in our own work, but our usual preference is for what Andy Royle and Bob Dorazio have called 'explicit HMs' in their influential 2008 book 'Hierarchical modeling and inference in ecology'.
Explicit HMs have an explicit description of how the data at hand relate to scientifically meaningful quantities that are latent, owing to the vagaries of sampling and data collection. These latter may include a variety of types of measurement errors, aggregation, censoring and truncation of the data, as well as non-random sampling of a population about which inferences are sought.
Key examples of such latent quantities with eminent scientific meaning are distribution, abundance, species richness, as well as the parameters in the dynamic processes that govern spatio-temporal variation in all of these, such as survival and recruitment rates for abundance, or colonization and extinction rates for species distributions. To us, explicit hierarchical modeling typically leads to what we like to think of as more scientific statistical models.
There are many reasons that data simulation must be part of the habitual methods used by an applied statistical modeller. In fact, we believe so strongly in the importance of data simulation for applied statistical analysis that we have written an entire chapter about this topic (this is Chapter 3 in AHM1).
We use data simulation all the time in our own work. To mention just a few of the crucial benefits (see Chapter 3 for a full list), simulated data let you decide whether the parameters in your model are really estimable, whether these estimates are biased, and they serve to validate your code for fitting a model.
And perhaps the most important benefit is to prove to yourself that you have understood a statistical model: we claim that if you have really understood a statistical model then you are able to simulate a data set under that model.
On the other hand, we can use data simulation to explain a statistical model. Indeed, throughout our books we use R code for assembling (i.e., simulating) a data set not only to just create a data set to play with, but, crucially, also to provide you with one more explanation of a particular model. This use of R data simulation code to explain a statistical model is one of the hallmarks of both books (and also of other books shown in www.hierarchicalmodels.com).
We have strived hard to make the material in the AHM books and especially the practical implementation of the models as widely understandable and intuitive as possible. This includes a hierarchical construction of the likelihood rather than the presentation of an integrated likelihood which may often leave non-statisticians baffled, and the frequent use of data simulation to explain a statistical model (see also above for more on this).
A large part of the material in both books has been developed for, during, and in the aftermath of countless AHM and related workshops that we have taught all over the world. Thus, we believe that we know what material is asked for by ecologists and related scientists, and we like to think that we also have a lot of experience in how to explain that material to them.
However, we show that we can go far beyond the mere depiction of static quantities such as the above (and not forgetting the associated maps of standard errors or confidence/credible intervals!). For instance, in AHM2 we also produce predictive maps of dynamic quantities such as the survival rate of a bird species all over Britain, or of colonization and extinction rates, along with detection probability, of another avian species in Switzerland.
Alas, it has taken us almost a decade to bring our baby to the world. After a couple of years into the project, we were so far behind schedule, but at the same time had written so much material already, that our publisher suggested we split the project into two volumes. Thus, we published AHM1 in late 2015 (but with an official publication year of 2016!). We then thought that it would take us at most 1–2 more years to produce volume 2. But this then took us another 5 years, and so AHM2 was published in the fall of 2020 (but again with an official 2021 publication date).
The two AHM volumes are part of what might be called a distributed research program on hierarchical modeling in ecology, which includes a number of other, related books, and web resources including Google group email lists; see the landing page for that meta-project at www.hierarchicalmodels.com. This collection of books, email lists, and software is likely to be augmented constantly in the future. For instance, a 2nd edition for the Bayesian Population Analysis book is on the horizon, as are additional R packages for fitting explicit HMs (e.g., spOccupancy; Doser et al. 2022).
In recent years, Ken Kellner (SUNY-ESF) has maintained unmarked and greatly expanded its capabilities, also beyond what we document in the two AHM books. This now also includes the possibility to specify additional sets of random effects for some models by the internal use by unmarked of the TMB software (Kristensen et al., 2016) as its computational engine.
On the Bayesian side we use good old WinBUGS (Lunn et al. 2000) and JAGS (Plummer 2003), which both use for model specification what is essentially the original BUGS model definition language (Gilks et al. 1994). BUGS is a very simple language that nevertheless enables users to build almost arbitrarily complex models by combining very simple basic modules exactly in the manner of a hierarchical statistical model. Thus, a complex stochastic system can be built up from a number of conditionally linked, much simpler elemental pieces.
Importantly, the BUGS language has proven to be supremely understandable to non-statisticians. Arguably, this has been the main reason for the very wide adoption of WinBUGS, later OpenBUGS and JAGS, and now also the new Nimble software (de Valpine et al. 2017). All the BUGS code in the AHM volumes should be working in Nimble with only very minor modifications and indeed, the BUGS code in AHM1 has been translated into Nimble; see https://github.com/nimble-dev/AHMnimble.
The well-known Stan software (Carpenter et al. 2017) is another probabilistic programming language (PPL) with a similar scope as JAGS and Nimble and that also implements a dialect of the BUGS model definition language. Owing to its gradient-based MCMC variant known as Hamiltonian Monte Carlo (HMC) it may be able to explore complex, multidimensional posterior "clouds" more swiftly or more reliably than do JAGS or Nimble.
However, unfortunately, HMC is unable to deal with discrete random effects directly and most models in the AHM volumes do contain such discrete random effects. What you must do when fitting these models in Stan is to define the marginal, or integrated, likelihood, in which these random effects are summed out; see the tutorial by Joseph (2020) as well as Turek et al. (2016) and Yackulic et al. (2020).
In fact, fitting these models with an integrated likelihood is exactly how they are implemented in unmarked. Thus, for the more numerate quantitative ecologists learning how to implement these models in their marginalized likelihood form may have substantial payoffs. However, we are convinced that for most of the audiences of our workshops and also of the AHM books, marginalizing discrete random effects out of the likelihood without having a statistician looking above their shoulder is beyond their level of understanding. Thus, we believe that use of Stan would often severely curtail the great modeling freedom that the other BUGS-based PPLs (especially JAGS and Nimble) now confer to them. As Mike Meredith (pers. comm.) has aptly put it: "In JAGS people can write their models as they see the world". By this is meant that you can write a hierarchical likelihood with all individual processes in sequence, rather than having to squash that neat scheme into a marginal likelihood. This is the reason for why we haven't really done much exploration of Stan for the fitting of explicit hierarchical models.
We note though that there are interesting initiatives to use Stan as the computing engine in canned R packages. For instance, Ken Kellner has recently developed the ubms R package (Kellner et al. 2022; see also cran.r-project.org/web/packages/ubms/index.html). This stands for 'unmarked Bayesian models using Stan' and can be described in short as a variant of unmarked that enables additional random effects to be specified in abundance and occupancy models. Examples of such random-effects factors might be regions within which sites are nested or observers in models of detection probability. The data formatting for input, model specification and output are extremely similar to unmarked, and thus ubms can be viewed as the Bayesian sister package of unmarked.
Clearly, over time we expect to see yet other, and even better, software with which we can fit explicit hierarchical models. Our big peroration to the current and prospective developers of such software is just this: PLEASE give serious consideration to the possibility of adopting the hugely successful BUGS modeling language for the specification of the models in your software. We believe that the ease with which BUGS code can be understood even for very complex hierarchical models makes it a serious candidate as a true lingua franca for hierarchical models.
Commented code for the package and any new developments or bug fixes can be found on GitHub at https://github.com/mikemeredith/AHMbook.
Four AHM extra data files:
We used to supply four additional data files that are used in AHM1: the Swiss tits (SwissTits_mhb_2004_2013.csv), Dutch wagtails (wagtail.Rdata), Swiss squirrels (SwissSquirrels.txt) and the Swiss MHB 2014 data (MHB_2014.csv). All four are now part of the AHMbook package (SwissTits, wagtail, SwissSquirrels, MHB2014). Mike Meredith has undertaken some data cleaning and reformatting and the help files for each data set show ways how to use these instead of .csv files with the code in the book.
However, in case you want to replicate the analyses with the exact book code, here are the four files in the original format for download:
Download OLD text file with all R and BUGS code (in the printed AHM1book):
Solutions to exercises
At the end of most chapters in the AHM1 book you find a series of exercises. We had originally planned to publish their solutions later. Alas, we now see that this is unlikely to happen anytime soon, and we apologize for this. However, perhaps some of you may be interested in solving part or even all of them and if you did, then we would be delighted to receive solutions and post them on this website.
Marc, Andy, and Mike; last changes: 15 December 2021
Berliner, L.M. 1996. Hierarchical Bayesian time series models. Pages 15–22 in K. Hanson & R. Silver (eds.) Maximum entropy and Bayesian methods. Kluwer Academic Publishers, Dordrecht, The Netherlands.
Carpenter, B., Gelman, A., Hoffman, M.D., Lee, D., Goodrich, B., Betancourt, M., Brubaker, M., Guo, J., Li, P. & Riddell, A. 2017. Stan: A probabilistic programming language. Journal of Statistical Software, 76, 1–32.
Cooch, E. & White, G. 2019. Program MARK: a gentle introduction. Available in pdf format for free download at http://www.phidot.org/software/mark/docs/book.
Crawley, M.J. 2005. Statistics. An introduction using R. Wiley, Chichester, West Sussex.
Cressie, N. & Wikle, C.K. 2011. Statistics for spatio-temporal data. Wiley.
Doser, J.W., Finley, A.O. Kéry, M., & Zipkin, E.F. 2022. spOccupancy: An R package for single species, multispecies, and integrated spatial occupancy models. Submitted.
Fiske, I. & Chandler, R. 2011. unmarked: an R package for fitting hierarchical models of wildlife occurrence and abundance. Journal of Statistical Software, 43, 1–23.
Gilks, W.R., Thomas, A. & Spiegelhalter, D.J. 1994. A language and program for complex Bayesian modelling. Statistician, 43, 169–177.
Joseph, M.B. 2020. A step-by-step guide to marginalizing over discrete parameters for ecologists using Stan. Accessed on 1 August 2020. https://mbjoseph.github.io/posts/2020-04-28-a-step-by-step-guide-to-marginalizing-over-discrete-parameters-for-ecologists-using-stan/.
Kellner, K.F., Fowler, N.L., Petroelje, T.R., Kautz, T.M., Beyer, D.E., & Belant, J.L. 2021. ubms: An R package for fitting hierarchical occupancy and N-mixture abundance models in a Bayesian framework. Methods in Ecology and Evolution, in press.
Kéry, M. & Royle, J.A. 2016. Applied hierarchical modeling in ecology—Modeling distribution, abundance and species richness using R and BUGS. Volume 1: Prelude and Static Models. Elsevier, Academic Press.
Kéry, M. & Royle, J.A. 2021. Applied hierarchical modeling in ecology—Modeling distribution, abundance and species richness using R and BUGS. Volume 2: Dynamic and Advanced Models. Elsevier, Academic Press.
Kéry, M. & Schaub, M. 2012. Bayesian population analysis using WinBUGS – A hierarchical perspective. Academic Press, Waltham, MA.
Kristensen, K., Nielsen, A., Berg, C., Skaug, H., & Bell, B. 2016. TMB: Automatic differentiation and Laplace approximation. Journal of Statistical Software, 70, 1–21.
Lunn, D.J., Thomas, A., Best, N. & Spiegelhalter, D. 2000. WinBUGS - A Bayesian modelling framework: concepts, structure, and extensibility. Statistics and Computation, 10, 325–337.
Plummer, M. 2003. JAGS: a program for analysis of bayesian graphical models using Gibbs sampling. Proceedings of the 3rd International Workshop in Distributed Statistical Computing (DSC 2003), March 20–22 (eds K. Hornik, F. Leisch& A. Zeileis), pp. 1–10, Technische Universität, Vienna, Austria.
Royle, J.A. & Dorazio, R.M. 2008. Hierarchical modeling and inference in ecology. The analysis of data from populations, metapopulations and communities. Academic Press, New York.
Turek, D., de Valpine, P., & Paciorek, C.J. 2016. Efficient Markov chain Monte Carlo sampling for hierarchical hidden Markov models. Environmental and Ecological Statistics, 23, 549–564.
de Valpine, P., Turek, D., Paciorek, C.J., Anderson-Bergman, C., Lang, D.T. & Bodik, R. 2017. Programming with models: writing statistical algorithms for general model structures with NIMBLE. Journal of Computational and Graphical Statistics, 26, 403–413.
Yackulic, C.B., Dodrill, M., Dzul, M., Sanderlin, J.S., & Reid, J.A. 2020. A need for speed in Bayesian population models: a practical guide to marginalizing and recovering discrete latent states. Ecological Applications, 30, e02112
